• Rating：12VDC 50mA
• Travel：≥1.0 mm
• Contact Resistance：50mΩ Max
• Insulation Resistance：100MΩ min(250VDC)
• Dielectric Strength：250VAC 50/60Hz FOR 1 min
• Operating Force：≥200g
• Electric Life：100,000 cycles
• Operating Temperature Rang：-20℃ ~ + 70℃
|
 |
   |
| Part Number | Rating | Contact Resistance | Insulation Resistance | Dielectric Strength | Operating Force | Electric Life | Operating Temperature Rang | Travel | PDF下載 |
|---|---|---|---|---|---|---|---|---|---|
| R596-1L(With LED) | 12VDC 50mA | 50mΩ Max | 100MΩ min(250VDC) | 250VAC 50/60Hz FOR 1 min | ≥200g | 100,000 cycles | -20℃ ~ + 70℃ | ≥1.0 mm | 暫無 |
| R596-1 | 12VDC 50mA | 50mΩ Max | 100MΩ min(250VDC) | 250VAC 50/60Hz FOR 1 min | ≥200g | 100,000 cycles | -20℃ ~ + 70℃ | ≥1.0 mm | 暫無 |
| R596-1ML(With LED) | 12VDC 50mA | 50mΩ Max | 100MΩ min(250VDC) | 250VAC 50/60Hz FOR 1 min | ≥200g | 100,000 cycles | -20℃ ~ + 70℃ | ≥1.0 mm | 暫無 |
| R596-1M | 12VDC 50mA | 50mΩ Max | 100MΩ min(250VDC) | 250VAC 50/60Hz FOR 1 min | ≥200g | 100,000 cycles | -20℃ ~ + 70℃ | ≥1.0 mm | 暫無 |
| R596B-1011L(With LED) | 12VDC 50mA | 50mΩ Max | 100MΩ min(250VDC) | 250VAC 50/60Hz FOR 1 min | ≥200g | 100,000 cycles | -20℃ ~ + 70℃ | ≥1.0 mm | 暫無 |
| R596B-1011 | 12VDC 50mA | 50mΩ Max | 100MΩ min(250VDC) | 250VAC 50/60Hz FOR 1 min | ≥200g | 100,000 cycles | -20℃ ~ + 70℃ | ≥1.0 mm | 暫無 |
| R596B-105L(With LED) | 12VDC 50mA | 50mΩ Max | 100MΩ min(250VDC) | 250VAC 50/60Hz FOR 1 min | ≥200g | 100,000 cycles | -20℃ ~ + 70℃ | ≥1.0 mm | 暫無 |
| R596B-105 | 12VDC 50mA | 50mΩ Max | 100MΩ min(250VDC) | 250VAC 50/60Hz FOR 1 min | ≥200g | 100,000 cycles | -20℃ ~ + 70℃ | ≥1.0 mm | 暫無 |
| R596B-1012L(With LED) | 12VDC 50mA | 50mΩ Max | 100MΩ min(250VDC) | 250VAC 50/60Hz FOR 1 min | ≥200g | 100,000 cycles | -20℃ ~ + 70℃ | ≥1.0 mm | 暫無 |
| R596B-1012 | 12VDC 50mA | 50mΩ Max | 100MΩ min(250VDC) | 250VAC 50/60Hz FOR 1 min | ≥200g | 100,000 cycles | -20℃ ~ + 70℃ | ≥1.0 mm | 暫無 |
| R596B-1311L(With LED) | 12VDC 50mA | 50mΩ Max | 100MΩ min(250VDC) | 250VAC 50/60Hz FOR 1 min | ≥200g | 100,000 cycles | -20℃ ~ + 70℃ | ≥1.0 mm | 暫無 |
| R596B-1311 | 12VDC 50mA | 50mΩ Max | 100MΩ min(250VDC) | 250VAC 50/60Hz FOR 1 min | ≥200g | 100,000 cycles | -20℃ ~ + 70℃ | ≥1.0 mm | 暫無 |
| R596B-1RL(With LED) | 12VDC 50mA | 50mΩ Max | 100MΩ min(250VDC) | 250VAC 50/60Hz FOR 1 min | ≥200g | 100,000 cycles | -20℃ ~ + 70℃ | ≥1.0 mm | 暫無 |
| R596B-1R | 12VDC 50mA | 50mΩ Max | 100MΩ min(250VDC) | 250VAC 50/60Hz FOR 1 min | ≥200g | 100,000 cycles | -20℃ ~ + 70℃ | ≥1.0 mm | 暫無 |
| R596B-1011ML(With LED) | 12VDC 50mA | 50mΩ Max | 100MΩ min(250VDC) | 250VAC 50/60Hz FOR 1 min | ≥200g | 100,000 cycles | -20℃ ~ + 70℃ | ≥1.0 mm | 暫無 |
| R596B-1011M | 12VDC 50mA | 50mΩ Max | 100MΩ min(250VDC) | 250VAC 50/60Hz FOR 1 min | ≥200g | 100,000 cycles | -20℃ ~ + 70℃ | ≥1.0 mm | 暫無 |
| R596B-1012ML(With LED) | 12VDC 50mA | 50mΩ Max | 100MΩ min(250VDC) | 250VAC 50/60Hz FOR 1 min | ≥200g | 100,000 cycles | -20℃ ~ + 70℃ | ≥1.0 mm | 暫無 |
| R596B-1012M | 12VDC 50mA | 50mΩ Max | 100MΩ min(250VDC) | 250VAC 50/60Hz FOR 1 min | ≥200g | 100,000 cycles | -20℃ ~ + 70℃ | ≥1.0 mm | 暫無 |
